April 23, 2021

Shelly Sense & Trigger Driver for ELAN

What does this driver do?

This official Shelly driver allows an Elan system to monitor a Shelly device and provide feedback and event triggers based on the devices switch input.

The Shelly Sense Driver can help add Elan functionality to systems that there may not be driver for, like older or existing AC, alarms, garage openers or sprinklers. Shelly’s small size and ability to wire directly into 24v/110v/240v means it can be added to any legacy units to provide control and/or feedback.

This driver is compatible with any Shelly device that supports inputs, as well as the Shelly Button. The Shelly Button is designed to help you easily activate or deactivate any device or scene manually with just a click. Additionally, Shelly Button is so small and convenient, you can carry it with you absolutely everywhere.

Features:

  • Shelly Events: When a momentary switch is connected to the switch input ELAN can read the following events:
    • Short Push
    • Long Push
    • Double Short Push
    • Triple Short Push
    • Short then Long Push
    • Long then Short Push
  • Input status: Using the conventional ELAN sense input objects the driver can feed back to ELAN if the switch input of the device is currently open or close circuit.
  • Highly responsive: Faster than any other driver on the market as built without the use of action URL commands, as recommended by Shelly.
  • (New Oct 2023) Support for V2 API Plus and Pro models added
  • Intrinsic Platinum Integration – Official Shelly driver
  • Driver uses Intrinsic(Athena) technology for key free licensing, update alerts and enhanced support

Current version number: 21.5.2 (V1) and 24.4.2 (V2/Plus & Pro)

Our Shelly Sense & Trigger Driver for ELAN is compatible with:

Any Shelly device that allows inputs, including:

  • Shelly Button 1
  • Shelly 1
  • Shelly 1PM
  • Shelly 2.5
  • Shelly 4
  • Shelly i3
  • Shelly i4

The Intrinsic difference

Our drivers are all developed in-house, in the UK so you can be sure of the highest reliability and responsiveness when updates are required. We never use open source code or code libraries. All of our drivers are thoroughly tested in-house as well as externally through our Beta Programme before being offered on our website.

Support

All of our drivers/modules are supported free of charge through our Online Support system. We offer comprehensive support for all of our software that requires the purchase of a license key for as long as they are listed on the Intrinsic Dev website. If it’s your first time installing a driver or if you believe there is a technical problem simply submit a ticket via our Online Support system.

Enhanced support

We also offer Enhanced Remote Support for each control platform. This support is charged in 30 minute intervals where we are pleased to advise on anything that falls outside of standard driver queries, including, but not limited to, driver installation, wider system integration/programming, general training and system design.

License

All of our software is available to download free of charge but will require licensing to function. Unless specifically noted only one license is required per controller/processor. You can run as many devices as required up to the limit supported by your chosen control platform.

Easy setup

All of our drivers/modules come with comprehensive Integration Notes to ensure the easiest possible set up of our software. Many also have Installation Tutorial videos to further assist you. Please ensure you refer to these resources each time you install a new driver/module.

Feedback

If you have any suggestions on new features or changes you would like to see to a driver/module then please let us know via our Online Support system.
